Product Details:
|
| Type: | Cable Accessories | Material: | Silicone Rubber |
|---|---|---|---|
| Color: | RED/BLACK/GREEN/YELLOW/WHITE | Application: | Wire Connecting |
| Product Name: | Load Break Connector 10KV | Usage: | Connecting Cable |
| Highlight: | 630A EPDM Elbow Cable Connector,EPDM Separable Elbow Cable Connector,Load Break Connector 10KV |
||
| Color: | Black | Material: | EPDM |
|---|---|---|---|
| Type: | Cable Accessories | Application: | Power Plant |
| Ratio Current: | 630A | Voltage: | 10kv |
| Standard: | IEC60502 | ||
| High Light: |
10KV load break connector,63kA load break connector,600A Elbow Cable Connector |
||
Cable Accessories Of 630A 10KV EPDM Rubber Rear Separable Connector For Electrical Cabinet
The 20kV expandable lightning arrester provides overvoltage and lightning protection for the 20kV power system. The application of non-linear resistors for arrester resistors has the advantages of low residual voltage, large current capacity, and flat steep waves. Ensure the normal operation of the power system.
Applicable fields:
The product is small and compact, and the interface size complies with the EN50180/50181 standard C interface. It can be used for ring network cabinets, branch boxes, etc., as a front plug and rear outlet extension branch.
Electrical Performance
| Description | Technical Parameters |
| Rated voltage | 10kV |
| Rated current | 630A |
| 5 minutes power frequency withstand voltage | 39 kV |
| Partial Discharge | Q≤10pC@15 kV |
| Lightning impulse withstand voltage | 95 kV |
| Short-time withstand current | 20kA,2S |
| Peak withstand current | 63kA |
| Guideline:GB/T12706.4,IEC60502-4 | |
Dimensions
FAQ
1. Who are we?
We are professional in cold shrink industry. Our products have been exported to America, Australia, Egypt, Taiwan, India, Indonesia, Egypt, Spain, Italy and Germany etc, Europe countries. Currently, we already cooperated many famous companies in electrical and telecommunication industry.
2. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.What can you buy from us?
cold shrink series sealing products, including customized processing machines and products kits, for examples: processing winding and expanding machines, spiraling strip/tube supporting material, EPDM cold shrink tube and silicone cable accessories kit in telecommunication and electrical power industry.
4. Why should you buy from us not from other suppliers?
Years focus on telecom and power infrastructure material, with experienced engineer and workers, with turnkey solution for cold shrink line to solve all your problem in this industry with competitive price.
5. What services can we provide?
Accepted Delivery Terms: FOB, CIF, EXW standard international terms and welcome commercial terms discussion;
Accepted Payment Currency: USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T, L/C, Credit Card, PayPal, Western Union, Cash, Escrow;
Language: English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
Shipment: express, sea and air shipping.
Contact Person: Mr. Richard Lee
Tel: +8618627678155
