High Power Cold Shrink Terminal Cable Accessory Termination Kits Silicone Rubber

Product name:

High Standard Power Cable Accessory Termination Kits Cold Shrink Terminal

The cold shrink termination is factory expanded on a removable inner supporting core,Once the termination is positioned onto the cable core,the supporting core is unwound and removed.and the live momory action of the material shrinks ther termination kit includes all the necesary componets to make the installation.

Product Features:

1. Simple installation, requires noly workman's hands.

2. No tool or heat required.

3. Seals tight, retains its resiliency and pressure even after years of aging and exposure.

4. Resists moisture.

5. Good thermal stability

6.Excellet wet electrical properties

Picture for your reference.

• Applicable scope

  1Kv-35Kv outdoor Rohs certificated silicone cold shrink cable accessories : It is widely used for waterproof seal in coaxial cables on telecommunication base stations, N-type connector, 1/2 jumper, Din head and 1/2 jumper connector. It can be used as a waterproof seal for cable television connector, connecting wires and cables, insulation seal for other types of connection.

  Rubber Typical Properties



  Properties	Test Method	Typical Value
  Color	/	Black
  Ultimate Tensile	ASTM D412-75	9.0MPa
  Ultimate Elongation	ASTM D412-75	750%
  Tear Resistance	ASTM D624C-73	30KN/m
  Fungus Resistance	ASTM G21 28 days exposure	No Growth
  Dielectric Strength	ASTM D149-75 @1.75 Original	21KV/m
  	7days in water at 90℃	20.5KV/m
  Volume resistance	ASTM D257	3.4×1015Ohm.cm



  All values are averages and are not intended for specification purposes.

•



  FAQ

  1. Who are we?
  We are professional in cold shrink industry. Our products have been exported to America, Australia, Egypt, Taiwan, India, Indonesia, Egypt, Spain, Italy and Germany etc, Europe countries.



  2. How can we guarantee quality?
  Always a pre-production sample before mass production;
  Always final Inspection before shipment;


  3.What can you buy from us?
  cold shrink series sealing products, including customized processing machines and products kits, for examples: processing winding and expanding machines, spiraling strip/tube supporting material, EPDM cold shrink tube and silicone cable accessories kit in telecommunication and electrical power industry.



  4. Why should you buy from us not from other suppliers?
  Years focus on telecom and power infrastructure material, with experienced engineer and workers, with turnkey solution for cold shrink line to solve all your problem in this industry with competitive price.


  5. what kind of pacakge do you use?

  Plastic bag with carton package
