Product Details:
|
| Material: | Silicone Rubber | Width: | 25/50mm |
|---|---|---|---|
| Length: | 5m | Thickness: | 03/0.5/0.8mm |
| Color: | Yellow,green,red,black Or Customized | Type: | Self-fusing |
| Temperature: | 180°C | Application: | Cable Insulation |
| Highlight: | Self fusing silicone rubber tape,Silicone rubber tape,electrical tape |
||
Self fusing silicone rubber electrical tape resistance to extreme low and high temperature
| Product | Color | Normal Specification (W*T*L) |
| ZKST-5005-R | Red | 50mm*0.5mm*5m |
| ZKST-5005-Y | Yellow | 50mm*0.5mm*5m |
| ZKST-5005-G | Green | 50mm*0.5mm*5m |
| ZKST-5005-B | Black | 50mm*0.5mm*5m |
Self fusing silicone rubber electrical tape resistance to extreme low and high temperature Technical Parameters:
| No. | Items | Test standard | Unit | Results |
| 1 | Hardness | GB/T 531.1-2008 | Shores A | 50±10 |
| 2 | Tensile strength | GB/T 528-2009 | Mpa | ≥4.5 |
| 3 | Elongation at break | GB/T 528-2009 | % | ≥350 |
| 4 | Dielectric coefficient | GB/T1408.1-2006 | KV/mm | ≥22 |
| 5 | Volume resistivity | GB/T1410-2006 | Ω.cm | ≥1.3*1015 |
| 6 | Self-adhesive | ASTM D2148 | N/cm | >3.5 |
| 7 | Water absorption | % | <0.9 | |
| 8 | density | GB/T 20631.2 | g/cm3 | <1.5 |
| 9 | Flame retardant | grade | UL-94 | V0 |
| 10 | Heat resistant temperature | 180 | ||
| 11 | Withstand voltage | 15KV | ||
| 12 | Color | Red, yellow, green etc |
Features:
●Self fusing rapidly in seconds, creating a stable airtight, waterproof and moisture seal
●High voltage insulation up to 35KV under continous H Class high Temperature 180℃
●Good track, arc and ozone resistance
●Wide temperature range, suitable for working environment from -60℃~260℃
●Excellent waterproof, Good weather, UV, Corrosion and age resistance
●High flexibility, can nearly recover to original status after stretched
Application:
Self fusing silicone rubber tape is a multi-purpose tape, composed of excellent self-fusing silicone rubber with easy-tear liner.
With a lot of advantages and characteristics in one, such as fast fusion in seconds, insulation, waterproof, resistance to extreme low and high temperature, moisture, weather, arc, ozone, track, corrosion and age, it is not only widely used for electrical insulation in power industry, but also for emergency and all-purpose repair.
Moreover, it performs well for underwater application.
